| d1 | t min | s |
| M2 | 0.8 | 0.9 |
| M2.5 | 1.2 | 1.3 |
| M3 | 1.2 | 1.5 |
| M4 | 1.5 | 2 |
| M5 | 2 | 2.5 |
| M6 | 2 | 3 |
| M8 | 3 | 4 |
| M10 | 4 | 5 |
| M12 | 4.8 | 6 |
| M14 | 5.6 | 6 |
| M16 | 6.4 | 8 |
| M20 | 8 | 10 |
| M24 | 10 | 12 |
DIN 914 - Socket Set Screws With Cone Point Specifications
DIN 914 - Socket Set Screws With Cone Point Specifications
*All measurements in millimeters (mm)*
All information is strictly informative
MATRIAL : STAINLESS STEEL 304, 304L, 316, 316L, 317L, 309, 310, 904L, SUS-630, UB-6, B8, B7
